5 WATT RESISTOR 0.39 ohm

Peavey 15 inch 1200W Lo Max® Subwoofer Power capacity 4800 W Peak 2400 W Program 1200 W Continuous Sensitivity 95.1 dB / 1 W 1m Usable freq. range 30Hz - 500 Hz Cone Kevlar® impregnated cellulose Voice coil diameter 4in / 100 mm Voice coil material Polyimide coated copper ribbon wire Polyimide-impregnated fiberglass former Nomex® stiffener Solderless diffusion welded OFHC copper leads

PEAVEY 15 inch Lo Max Replacement Basket 00560300

Tenma compact soldering station features a digital display and low profile casing. Its compact design will fit on any tool bench and is small enough for convenient storage. The efficient, thermostat-controlled, 60-watt output of this unit provides almost instant working temperatures with outstanding precision. Heat Temperature Max: 896°F Tips 21-10117

Phenolic Ring Tweeter low-mass paper cone + dust cap, 3/4 in Specifications: • Power handling: 30 watts RMS/60 watts max • VCdia: 3/4" • Impedance: 8 ohms • Re: 6.9 ohms • Frequency response: 2,000-15,000 Hz • Fs: 1084 Hz • SPL: 90.3 dB 1W/1m • Dimensions: Overall diameter: 4-1/4", Cutout diameter: 3-3/16" (plus notches for terminals), Depth: 1-1/4".

ScanSpeak Illuminator 19mm (3/4 in) Textile Ring Soft Dome Neodymium Tweeter 4 ohm 55.5mm (2.18 in) diameter flange with 29.3mm (1.15 in) depth Excellent choice for both home hi-fi and autosound applications Illuminator tweeters continue on with the heritage of the renowned Revelator series. The large-roll surround and textile dome diaphragm provide a flat frequency response to above 30KHz with outstanding off-axis dispersion. The face plates are die cast in aluminum for a beautiful look with maximum mechanical stability. D2004-602000 is optimized to offer small package sizes that can fit into tight spaces such as compact cabinets and automotive trim pieces. The back chamber is die cast in aluminium and designed with a contoured shape that functions as a heat sink in high power applications.

EMINENCE 15 inch 8 ohm Professional Series Woofer 700W RMS 1400W program. Recommended for professional audio and bass guitar as a low distortion woofer or subwoofer in vented enclosures. Also works in a sealed enclosure for bass guitar. Made in the USA. 7-year manufacturer warranty. View PDF for complete specs. Call 770 455 0571 for free shipping. 8 76358 00259 7

Apply pressure and turn your circuit on with this light touch EVQ-21504M tactile switch from Panasonic. This device has a maximum current rating of 0.02 A @ 15VDC. It has a SPST configuration. This tactile switch has an operating temperature range of -20 °C to 70 °C. The EVQ-21504M tactile switch has a PC pin termination style. This white round button actuator is 0.9 mm long. The maximum DC voltage rating is 15 VDC. This product is 6 mm long, 4.3 mm tall and 6.3 mm deep.

EV 15 inch woofer ZLX series 8 ohm F01U286313 F.01U.286.313 F01U268468 EV Factory Replacement Woofer - Pleated cloth edge with silicon treatment - Size: 15.125 385mm - Hole cut-out: 13.75 350mm - Depth: 6 - Voice coil: 2 - Magnet: 50 oz - Impedance: 8 ohms, Re: 5.3 ohms - Power: 180 watts RMS, 360 watts max - Response: 25-3000 Hz - Sensitivity: 94 dB, 1 watt, 1 meter

The HA13155 is four-channel BTL amplifier IC designed for car audio, featuring high output and low distortion, and applicable to digital audio equipment. It provides 33 W output per channel, with a 13.7 V power supply and at Max distortion. IC REPLACES 448-48 Pin to pin with HA13150A/HA13151/HA13152/HA13153

HITACHI HA13157 is four-channel BTL amplifier IC designed for car audio, featuring high output and low distortion, and applicable to digital audio equipment. It provides 33 W output per channel, with a 13.7 V power supply and at Max distortion. Pin to pin with HA13150A/HA13151/HA13152/HA13153/HA13155

The HA13158 is four-channel BTL amplifier IC designed for car audio, featuring high output and low distortion, and applicable to digital audio equipment. It provides 34 W output per channel, with a 13.7 V power supply and at Max distortion. Pin to pin with HA13150A HA13151 HA13152 HA13153 HA13155 HA13157

HITACHI HA13159 is four-channel BTL amplifier IC designed for car audio, featuring high output and low distortion, and applicable to digital audio equipment. It provides 37 W output per channel, with a 13.7 V power supply and at Max distortion. Pin to pin with HA13153A/HA13154A/HA13155/HA13157/HA13158/HA13158A

EMINENCE 15 inch 8 ohm Professional Series Woofer 1250W RMS 2500W program. Recommended for professional audio subwoofer and woofer applications in vented enclosures. Made in the USA. 7-year manufacturers warranty! View PDF for complete specs. Call 770 455 0571 for free shipping.

EV 15” Two-Way Dual Manifolded HF 60° x 45° Fullrange Loudspeaker System. The PX2152 uses two DVX3150 woofers, a high output 15-inch woofer with forced air cooling, in a vented enclosure. HF is delivered by dual ND2-16 compression drivers precisely summed in a manifold for increased power handling, maximum SPL, and low distortion.

D7H20 D7L16 3-Channel Convergence Correction Circuit 38v 5a 15Khz max LO
